A Reference Class with the Ultimate in Picture and Sound Quality

The UB9000 reference-class Ultra HD Blu-ray player uses Panasonic’s unique chroma and HDR processing technologies to reproduce images with cinema-level quality at home. This combines with a structure and components that pursue the highest possible audio quality, to bring you overwhelmingly beautiful pictures and sounds.

*Design, functions and specifications are subject to change without notice.

Ultra HD Blu-ray Playback (4K/HDR) - Ultimate Picture Quality with the New HCX Processor
Multi HDR Support - HDR10+ and Dolby Vison Supported
Premium Sound Quality for Various Audio Devices - Unique Audio Technologies Achieve Rich Sound Reproduction
Designed for Comfortable and Smart Image Viewing - Compatible with 4K VOD/ Viewing Experience Controlled via Voice
The Stylish Design Provides a High-quality Presence - Refrerence Design

Technical Specifications :

PLAYABLE DISCS

BD-ROM
- Ultra HD Blu-ray/ FULL HD 3D/ BD-Video
  - yes
BD-RE/ BD-RE DL (Ver.3)
- BDAV/ BDMV/ JPEG/ MPO
  - yes
BD-R (Ver.1.3) / BD-R DL (Ver.2)
- BDAV/ BDMV/ MKV/ JPEG/ MPO
  - yes
DVD
- DVD-Video
  - yes
DVD-R*1/ DVD-R DL*1/ DVD-RW*1
- DVD-Video/ DVD Video Recording
  - yes
- AVCHD/ MKV(H.264/ HEVC)
  - yes/ yes* (*DVD-R/ DVD-R DL)
- FLAC/ WAV/ ALAC/ AIFF/ DSD/ WMA/ AAC/ MP3
  - yes (DVD-R/ DVD-R DL)
- JPEG/ MPO
  - yes (DVD-R/ DVD-R DL)
+R*1/ +R DL*1/ +RW*1
- Video/ AVCHD
  - yes
CD, CD-R/ -RW
- CD-DA/ DTS-CD
  - yes
- MKV(H.264/ HEVC)
  - yes (CD-R/ -RW)
- FLAC/ WAV/ ALAC/ AIFF/ WMA/ AAC/ MP3
  - yes (CD-R/ -RW)
- JPEG/ MPO
  - yes (CD-R/ -RW)

AUDIO SYSTEM

Dolby Audio (Dolby Digital/ Dolby Digital Plus/ Dolby TrueHD)
- yes (Decode and Bitstream Output*2)
DTS-HD Master Audio/ DTS-HD High Resolution Audio
- yes (Decode and Bitstream Output*2)
Dolby Atomos/ DTS:X
- yes (Bitstream Output*2)
FLAC
- yes (Max. 192 kHz/ 24 bit)
WAV
- yes (Max. 384 kHz/ 32 bit)
ALAC
- yes (Max. 96 kHz/ 32 bit (7.1ch), 176.4/192 kHz/ 32 bit (5.1ch))
DSD (DFF, DSF)
- yes (2.8 MHz (2ch/ 5.1ch), 5.6 MHz (2ch/ 5.1ch), 11.2 MHz (2ch))
AIFF
- yes (Max. 384 kHz/ 32 bit (2ch))

USB

Slot
- yes (2)
Front
- 1 (USB 2.0 High Speed)
Rear
- 1 (USB 3.0 Super Speed)
Playback
- FLAC/ WAV/ ALAC/ AIFF/ DSD (DFF, DSF)/ WMA/ AAC/ MP3
  - yes (Gapless Playback: FLAC/ WAV/ AIFF/ DSD(DFF))
- MKV(H.264/ HEVC)/ MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC)
  - yes
- PS (MPEG-2) / AVCHD/ AVCHD 3D
  - yes
- JPEG/ MPO
  - yes

HIGH QUALITY PICTURE

HCX Processor for Ultra HD Blu-ray
- yes
HDR
- Feature
  - yes
- HDR10+
  - yes
- Dolby Vision
  - yes
- Hybrid Log Gamma (HLG)
  - yes
HDR Optimiser
- yes
4K Up-scaling*4*5
- 60p/ 50p/ 4:4:4 (HDMI2.0)
  - yes
- 24p/ 25p
  - yes
4K Direct Chroma Up-scaling*4
- yes
4K Networking (4K Video*6 Playback/ 4K JPEG Playback*4)
- yes
4K VOD
- yes*7
Picture Type Presets*8
- Normal/ Cinema/ Fine Cinema/ Retro Cinema/ Animation/ Live
Block/ Randam/ Mosquito Noise Reduction
- yes
Video on Demand in HD Quality
- yes
Ultra HD Premium
- yes
THX Certified
- yes
Deep Colour
- yes
x.v.Colour*9
- yes

HIGH QUALITY SOUND

TWIN HDMI
- yes
Pure Audio on HDMI (HDMI Low Clock Jitter Process)
- yes
High Quality Network Audio Playback*10
- yes (FLAC/ WAV/ ALAC/ AIFF/ DSD/ WMA/ AAC/ MP3)
High Clarity Sound Premium
- yes
Digital Tube Sound
- yes (Up to 192 kHz/ 32 bit)
Surround Re-Master*11
- yes (Up to 192 kHz/ 32 bit)
Audio D/A Converter
- yes
Insulator
- yes

SMART FEATURE

Unit Display
- yes (Dot Matrix)
Remote Control
- yes
Subtitle Position/ Brightness Adjustment
- yes
Compatible with Control4 Linking
- yes*3
HDAVI Control 5 (VIERA Link) / HDMI CEC
- yes
Mirroring with Smartphone/ Tablet*12
- yes
Internet Apps*13
- yes
Web Browser
- yes
Wireless LAN System
- yes (Built-in) IEEE802.11 a/b/g/n/ac
Network Contents Playback*10 (Client & Renderer)
- yes
External HDD Playback*14
- yes
Network Drive Access
- yes
BD-Live™*15
- yes

TERMINAL

HDMI Output
- yes (2)
Optical Output
- yes
Coaxial Output
- yes
Analogue Audio LR Output
- yes (XLR Balanced/ Gold Plated)
Analogue Audio 7.1ch Output
- yes (Gold Plated)
LAN (Ethernet) Terminal
- yes (for Ultra HD Blu-ray, Network Contents Playback*10, BD-Live™*15, Internet Apps*13 and Firmware Update)

OTHERS

Video System
- PAL/ NTSC
Power Supply
- AC 220-240 V, 50 Hz
Power Consumption
- Normal Use
  - 45 W
- Standby (Quick Start Off): Network Standby On
  - 2 W
- Standby (Quick Start Off): Network Standby Off
  - 0.4 W

DIMENSIONS, WEIGHT

Dimensions (W x H x D)
- 430 x 81 x 300 mm
Weight
- 7.8 kg

NOTIFICATION

NOTE
- *1 Discs recorded and finalized on recording devices.
  *2 HDMI connections and compatible equipment (e.g. AV Receiver) required.
  *3 Enabled by software update
  *4 For 4K Up-scaling playback a TV with same resolution is required.
  *5 For 4K/60p video, a high speed HDMI cable supporting 18 Gbps bandwidth is required.
  *6 MP4(4K/25p,30p) bit rate up to 100 Mbps/resolution up to 3840x2160.
  *7 Some network content services may not be available in your country.
  *8 Ultra HD Blu-ray and Photo (JPG/ MPO) are not supported.
  *9 This function is effective only when reproducing AVCHD data recorded with x.v.Color technology. The function cannot be used with BD-ROM or DVD-ROM discs. HDMI connection is required.
  *10 File formats that are not supported by your Network Contents server (DLNA compatible server, etc.) cannot be played.
  *11 CD sampling is done at 176.4/88.2 kHz.
  *12 A device that supports the Mirroring function and Android™ ver. 4.2 or higher is required.
  *13 Requires broadband Internet service.
  *14 The external HDD with capacities of 4TB or less in processing NTFS/ FAT32 data is supported. Playback is not possible with some external hard disk drives.
  *15 To enjoy content, you will need to insert a USB (1GB or more of free space/ sold separately). Requires broadband Internet service.
  *16 The analog 2-channel output terminal can also be used as an analog 7.1-channel output terminal.
  *17 Excluding the projecting parts.
  Specifications are subject to change without notice. All numbers given here are approximate.
WARNING:
- The recording and playback of content on this or any other device may require permission from the owner of the copyright or other such rights in that content. Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. It is your responsibility to ensure that your use of this or any other device complies with applicable copyright legislation in your country. Please refer to that legislation for more information on the relevant laws and regulations involved or contact the owner of the rights in the content you wish to record or playback.
  Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use.
  Specifications are subject to change without notice.
TRADEMARK NOTICE:
- Blu-ray Disc™, Blu-ray™, Ultra HD Blu-ray™ and the logos are trademarks of Blu-ray Disc Association.
  "AVCHD" and the "AVCHD" logo are trademarks of Panasonic Corporation and Sony Corporation.
  HDR10+™ logo is a trademark of HDR10+ Technologies, LLC.
  MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
  Dolby, Dolby Audio, Dolby Vision, and the double-D symbol are trademarks of Dolby Laboratories.
  For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, DTS-HD, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS-HD Master Audio is a trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.
  The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.
  DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks, or certification marks of the Digital Living Network Alliance.
  Android is a trademark of Google LLC.
  THX and the THX logo are trademarks of THX Ltd., registered in the United States and other countries.
