| CD Section |
| Supported Media |
Audio CD, CD (CD-R/CD-RW) * 8cm CDs not supported |
| Digital Audio Outputs |
| COAXIAL Connector |
RCA × 1 |
| COAXIAL Output Level |
0.5Vp-p |
| COAXIAL Output Impedance |
75Ω |
| OPTICAL Connector |
TOS (JEITA RC5720C) × 1 |
| Clock Sync Input |
| Clock Sync Connector |
BNC × 1 |
| Input Frequency |
10MHz |
| Input Impedance |
50Ω |
| Input Level (Rectangle Wave) |
Equivalent to TTL level |
| Input Level (Sine Wave) |
0.5 to 1.0Vrms |
| External Control |
| Trigger In (12V TRIGGER IN) |
3.5mm Mono mini jack × 1, Input level: 12V, 1mA |
| Trigger Out (12V TRIGGER THRU) |
3.5mm Mono mini jack × 1, Output level: 12V, Max current supply: 100mA |
| Power |
| Power Supply |
AC120V, 60Hz / AC220-240V, 50/60Hz |
| Power Consumption |
10W |
| Standby Power |
0.4W |
| Dimensions & Weight |
| Dimensions (W x H x D) |
444 × 111 × 333 mm (including protrusions) |
| Weight |
10.1kg |
| Operating Conditions |
| Operating Temperature |
+5℃ to +35℃ |
| Operating Humidity |
5% to 85% (no condensation) |
| Storage Temperature Range |
−20℃ to +55℃ |
| Included Accessories |
| Included Accessories |
AC cord, Remote control (RC-1338), AAA batteries × 2, Foot pads × 3, Owner's manual |
