| System Type |
2 ½ way, downwards firing port, with BassTraxTM Tractrix diffuser*, twin cavity loading system |
| Recommended amplifier power (Watt RMS) |
30- 200 |
| Continuous power handling (Watt RMS) |
100 |
|
Sensitivity (2.83 Volt @ 1m)
|
92dB |
| Nominal impedance |
8 Ohm |
| Frequency response (-6dB typical in room) |
30Hz - 34kHz |
| Drive unit complement |
1 x 200mm IsoFlare point source driver, multi-fibre bass/ midrange cone, FyneFluteTM surround with 25mm magnesium dome compression tweeter, neodymium magnet system. 1 x 200mm multi-fibre bass cone, FyneFluteTM surround. |
| Crossover frequency |
250Hz & 1.7kHz |
| Crossover type |
Bi-wired passive low loss, 2nd order low pass, 1st order high pass |
|
Dimensions - HxWxD
|
1111 x 338 x 380mm (43.7 x 13.3 x 15.0”) |
|
Weight - Each
|
30.4kg (67.0lb) |
