PRODUCT FEATURE
|
BENEFIT TO THE CUSTOMER
|
| X-ART tweeter, handmade in Berlin |
- Allows longer operation with fewer signs of fatigue
- Their breakup is prevented by the folded diaphragms, distortions are effectively reduced to a minimum
- Advanced dynamic range due to acoustically effective diaphragm surface that is 2.5 times bigger (compared to a classic tweeter according to the piston principle)
|
| The air velocity ratio of 4:1 during the sound generation by folded X-ART membrane |
Direct, fast response in the high-range even with complex transients
|
| In-phase, simultaneous operation of the woofers below 400 Hz |
- Dry, unstrained reproduction of the low-range
- Critical center area is played by a single driver without interference
|
| Ultra-light but extremely dimensionally stable woofer material (Carbon/Rohacell/Glass fiber) |
Excellent transient response even at high sound levels without breakup of the diaphragm
|
| Unique, horizontal 2.5-way system with 2 x 7" woofers |
Very high resolution of the stereo image and extremely wide stereo base
|
| Spacious bass reflex ports on the front |
- Bass reproduction with very low compression
- Allows positioning close to walls
|
| Highly efficient PWM amplifier for the woofer coupled with an A/ B amplifier for X-ART tweeter |
Low-distortion amplification at both low and high volume levels
|
| Linear frequency response of 38 Hz to 50 kHz |
Unbiased reproduction in a very wide frequency band
|
| Maximum Peak sound pressure per pair in 1 m ≥ 122 dB |
Powerful, compression-free sound reproduction even at very high sound levels
|
| Simple, stepless room acoustic adjustments over tweeter gain, low and high shelf filters |
Allows optimal adaptation to acoustically difficult listening environments
|
| Analog XLR and RCA inputs |
Optimized for balanced and unbalanced line signals
|
| Acoustically optimized cabinet geometry |
Reduction of unwanted reflections on the cabinets
|
| Directional sound radiation in vertical plane |
Reduction of early reflections on the surfaces of, e.g. mixing consoles, desks, etc.
|
| Volume control and on/off switch on the front |
Very easy to use
|
| Suitable for both near- and mid-field applications |
Enough headroom for different studio environments
|
