Speaker Configuration
7 x Scan-Speak Illuminator 30 mm, Tweeter 7 x Scan-Speak Illuminator 86 mm, Midrange 3 x Scan-Speak Discovery 212 mm, Woofer 1 x Scan-Speak Revelator 260 mm, Front Woofer
Amplifier
For tweeters: 7 x Bang & Olufsen ICEpower AM300-X For midranges: 7 x Bang & Olufsen ICEpower AM300-X For woofers: 3 x Heliox AM1000-1 For front woofer: 1 x Heliox AM1000-1
Frequency Range
15 – 43,000 Hz
Maximum Loudness @1m (SPL)
126 dB SPL
Bass Capability
123 dB SPL
Advanced Sound Features
Active Room Compensation Beam Width Control Beam Direction Control (5 sides) Thermal Protection Adaptive Bass Linearization
DESIGN
Designer
Materials
Aluminium Fabric Wood Oak Smoked oak
Dimensions
74.7 W x 125.3 H x 74.7 D cm
POWER
Power supply
Power cable
CONNECTIVITY
Wi-Fi
Wireless Power Link (24 bit / 48 kHz) WiSA (24 bit / 96 kHz)
External Source Required
Yes, Beosound Core Connectivity hub (which Connects to the optical-in and the USB of the BeoSound Shape) provides the wireless streaming Connectivity for BeoSound Shape. BeoSound Core fits into an empty tile.
Inputs and outputs
Power Link RCA XLR (fully balanced) USB Audio (24 bit / 192 kHz) S/P-DIF (24 bit / 192 kHz) Toslink (24 bit / 96 kHz) Digital Power Link (24 bit / 192 kHz)
Remote control
Bang & Olufsen App Beosound Essence Remote Beoremote One
