| Specification |
Details |
| D/A Converter |
THD <0.0008%, 20Hz - 20kHz, 24-bit, 1Vrms output |
| THD analog sources |
<0.0008%, 20Hz – 20kHz, 1Vrms output |
| Frequency response |
20Hz-20kHz +/- 0.1dB |
| S/N ratio (ref 1V output) |
>103 dB |
| Crosstalk @ 1kHz |
< -100dB |
| Max preamp output |
6Vrms single ended or 6Vrms + 6Vrms balanced |
| Fixed Line-out Mode |
Yes. The preamplifier can be disabled via the dedicated Edge app for iOS and Android. Within the app, simply turn off ‘preamplifier mode’ in the settings to run a line out via XLR or RCA to an integrated amplifier. |
| USB audio input |
USB Audio Class 2.0 supporting up to 24-bit 384kHz PCM, or up to DSD256 |
| USB drive input |
1 x USB 2.0 current limited to 1A, FAT32 / NTFS / HFS / HFS+ |
| Bluetooth |
4.1 (Smart/BLE enabled) A2DP/AVRCP supporting SBC, AAC, aptX and aptX HD |
| UPnP Connectivity |
Yes - Accessible via supported app |
| Chromecast built-in |
Yes |
| Roon Ready |
Yes (Requires a Roon subscription) |
| TOSLINK input |
16/24-bit 32-96kHz |
| Coax S/PDIF input |
16/24-bit 32-192kHz |
| Wi-Fi |
IEEE 802.11 b/g or n (2.4GHz), Encryption WEP, WPA, WPA2 |
| Ethernet |
IEEE 802.3, 10 Base-T or 100 Base-T |
| Max power consumption |
100W |
| Standby power consumption |
<0.5W |
| Dimensions |
120 x 460 x 405mm (4.7 x 18.1 x 15.9”) |
| Weight |
10.2kg (22.4lbs) |
| Chromecast built-in |
Hi-res wireless connectivity that's compatible with hundreds of Android and iOS apps. Chromecast built-in is a trademark of Google LLC |
| In the box |
Edge NQ Pre-amplifier and Network Player; 1.5M Power Lead; Edge Remote Control; 3 x AAA Batteries; Bluetooth Antenna; Wi-Fi Dongle; Edge Link Cable; Edge NQ User Manual |
