Construction Details
|
Resonance-optimised body, highly compressed wood chassis, core of natural medium-density wood fibre within an aluminium surround and upper layer incorporating a high tech synthetic compound
|
|
Speed Ranges
|
33 ⅓, 45 and 78 rpm
|
|
Drive Unit
|
Decoupled and resonance damped DC motor, flat belt-drive and plug-in power supply unit designed for worldwide use with all networks and power frequencies
|
|
Bearing
|
Polished and tempered steel shaft in a sintered bronze bushing, runs on a mirror of Teflon
|
|
Platter
|
Synthetic material, CNC-precision milled surface, 30mm thickness / 1.18 inch. Aluminium subplatter.
|
|
Speed Accuracy (Measured)
|
± 0.05 %
|
|
Power Consumption
|
Max. consumption: 5.5 Watt
Off mode: 0.0 Watt
|
|
Of The Integrated Phonopreamp By 1Khz
|
+52 dB (MM mode)
+72 dB (MC mode)
|
|
Amplification Of The Integrated Phonopreamp By 1Khz
|
< 0,02 % (MM mode)
< 0,03 % (MC mode)
|
|
Thd Of The Integrated Phonopreamp
|
-74 dB (MM mode)
-64 dB (MC mode)
|
|
S/N Of The Integrated Phonopreamp
|
± 0,5 dB
|
|
Riaa Accuracy Of The Integrated Phonopreamp
|
47 kOhm
|
|
Max. Output Voltage Of The Integrated Phonopreamp
|
< 10V
|
|
Total Weight
|
Approx. 7.6kg (incl. tonearm and cartridge)
|
|
Dimensions (W/D/H In Mm)
|
Approx. 420 x 350 x 125 (with tonearm)
|
|
Warranty
|
2 years*
* Provided the warranty card is fully completed and returned to Clearaudio within 2 weeks of purchase.
|
