| Specification |
Details |
| Number of Power Amps |
13 |
| Power Output (8 ohm, 20Hz - 20kHz, 0.05% 2ch Drive) |
150 watts per channel |
| Power Output (6 ohm, 1kHz, 0.7% 2ch Drive) |
190 watts per channel |
| Power Output (6 ohm, 1kHz, 1% 1ch Drive) |
190 watts per channel |
| Power Output (6 ohm, 1kHz, 10% 1ch Drive) |
210 watts per channel |
| Auto Speaker Setup by Microphone |
Audyssey MultEQ XT32 |
| Front Display |
2 Lines FLD |
| GUI Languages |
9 |
| System Remote Control |
RC-1261 |
| Power Consumption (in W) |
900W |
| Power Consumption No-Sound (ECO on/off) (in W) |
70W/125W |
| Standby Consumption (in W) |
0.1W |
| CEC Standby Consumption (in W) |
0.5W |
| Network Standby Consumption (in W) |
Less than 2.0W |
| Maximum Dimensions (Antenna, Horizontal) |
434 × 482 × 195 mm |
| Maximum Dimensions (Antenna, Vertical) |
434 × 482 × 259 mm |
| Maximum Dimensions (Antenna, w/o Antenna) |
434 × 472 × 195 mm |
| Weight |
23.6 kg |
| HDMI In/Out |
7/3 |
| Analog In/Out |
7+1 / 0 |
| Phono (MM) In |
Yes |
| Digital In: Optical / Coaxial |
2 / 2 |
| Multi-Room Out: Analog / Digital |
2 / 0 |
| Multichannel Pre-Out |
Yes (15.4) |
| Subwoofer Out |
4 (independent) |
| Number of Speaker Terminals |
15 |
| Speaker A/B Assignable |
Yes |
| Bi-Amp Drive Assignable |
Yes |
| Multi-Room Speaker Terminal Assignable |
Yes |
