Channels
|
-
9.2
-
Object-Based Configuration: 5.2.4
-
Object-Based Configuration: 7.2.2
-
With External Amplifier: 11.2
|
|
Power Output per Channel
|
2-Channel Driven: 105 W at 8 Ohms / 20 Hz to 20 kHz / 0.008% THD, 135 W at 6 Ohms / 1 kHz / 0.7% THD
|
|
Frequency Response
|
10 Hz to 100 kHz +1/-3 dB (Direct Mode)
|
|
Speaker Impedance
|
4 to 16 Ohms
|
|
DTS Compatibility
|
DTS-HD Master Audio, DTS:X
|
|
Dolby Compatibility
|
Dolby Atmos, Dolby Pro Logic IIz, Dolby TrueHD
|
|
Auro 3D Support
|
No
|
|
Upmixing Technology
|
Dolby Surround, DTS Neural:X, DTS Virtual:X, Dolby Atmos Height Virtualization Technology
|
|
Supported File Formats
|
AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
|
|
HDR Compatibility
|
HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma
|
|
Pass-Through Support
|
8K60p 4:4:4 (3D, BT.2020)
|
|
Upscaling
|
8K
|
|
GUI
|
Yes
|
|
Rear A/V Inputs
|
-
7 x HDMI
-
2 x 3RCA Component
-
3 x RCA Composite
-
2 x Optical TOSLINK
-
2 x Digital Coaxial
-
5 x Stereo RCA
-
1 x Stereo RCA (Phono) with Ground Screw
|
|
Rear A/V Outputs
|
-
3 x HDMI
-
1 x 3RCA Component
-
1 x RCA Composite
-
2 x RCA Subwoofer
-
1 x 11-Channel RCA Pre-Out
-
1 x Stereo RCA Zone 2 Pre-Out
|
|
Front I/O
|
-
1 x USB Type-A Input
-
1 x 1/4" / 6.35 mm Headphone Output
-
1 x 1/8" / 3.5 mm Setup Mic Input
|
|
Other Rear I/O
|
-
2 x Bluetooth/Wi-Fi Antenna Terminal Input
-
1 x AM Antenna Terminal Input
-
1 x FM Antenna Terminal Input
-
1 x RJ45 (Ethernet)
-
1 x DE-9 (RS-232C)
-
1 x 1/8" / 3.5 mm (12 V Trigger) Output
-
1 x 1/8" / 3.5 mm (IR) Input
-
1 x 1/8" / 3.5 mm (IR) Output
|
|
Speaker Connectors
|
11 x Binding Post Pairs
|
|
HDCP Support
|
Version 2.3
|
|
Audio Return Channel (ARC)
|
Yes, eARC
|
|
HDMI CEC
|
Yes
|
|
Input Impedance
|
47 Kilohms
|
|
Input Sensitivity
|
200 mV
|
|
Signal to Noise Ratio
|
100 dB (Direct Mode / IHF-A)
|
|
Wireless Audio Protocols
|
AirPlay 2, HEOS
|
|
Virtual Assistant Support
|
Amazon Alexa, Apple Siri, Google Assistant, Josh.ai
|
|
AC Input Power
|
230 VAC, 50 Hz
|
|
Power Consumption
|
-
Active: 660 W
-
No Sound (ECO Off): 100 W
-
No Sound (ECO On): 60 W
-
CEC Standby: 0.5 W
-
Standby: 0.1 W
|
|
Dimensions (W x H x D)
|
-
17.1 x 9.3 x 15.3" / 43.4 x 23.6 x 38.9 cm (Antenna Up)
-
17.1 x 6.6 x 15.3" / 43.4 x 16.8 x 38.9 cm (Antenna Down)
-
17.1 x 6.6 x 14.9" / 43.4 x 16.8 x 37.8 cm (Antenna Removed)
|
|
Weight
|
27.6 lb / 12.52 kg
|
