Projection System
|
3LCD Technology, RGB liquid crystal shutter
|
|
LCD Panel
|
0.61 inch with C2 Fine
|
|
Color Light Output
|
3,000 Lumen
|
|
White Light Output
|
3,000 Lumen
|
|
Resolution
|
4K PRO-UHD, 16:9
|
|
High Definition
|
4K enhancement
|
|
Aspect Ratio
|
16:09
|
|
Contrast Ratio
|
100,000 : 1
|
|
Light source
|
Lamp
|
|
Lamp
|
UHE, 250 W, 3,500 h durability, 5,000 h durability (economy mode)
|
|
Keystone Correction
|
Manual vertical: ± 30 °, Manual horizontal ± 30 °
|
|
Colour Video Processing
|
10 Bits
|
|
2D/3D Frequency Image
|
240 Hz / 480 Hz
|
|
2D Vertical Refresh Rate
|
192 Hz - 240 Hz
|
|
3D Vertical Refresh Rate
|
400 Hz - 480 Hz
|
|
Colour Reproduction
|
Upto 1.07 billion colours
|
|
Throw Ratio
|
1.32 - 2.15:1
|
|
Zoom
|
Manual, Factor: 1 - 1.62
|
|
Lens
|
Optical
|
|
Lens Shift
|
Manual - Vertical ± 60 %, horizontal ± 24 %
|
|
Screen Size
|
40 inches - 500 inches
|
|
Projection Distance Wide/Tele
|
2.95 m - 4.77 m ( 100 inch screen)
|
|
Projection Lens F Number
|
1.49 - 1.77
|
|
Projection Lens Focal Length
|
18.2 mm - 29.2 mm
|
|
Projection Lens Focus
|
Manual
|
|
Interfaces
|
USB 2.0 Type A (2x), USB 2.0 Type Mini-B, HDMI in (2x), Stereo mini jack audio out, Bluetooth
|
|
Epson iProjection App
|
Ad-Hoc / Infrastructure
|
|
Security
|
Kensington lock
|
|
3D
|
Active
|
|
2D Colour Modes
|
Dynamic, Natural, Cinema, Bright Cinema
|
|
3D Supported formats
|
Side by side, Top and bottom
|
|
Other features
|
3D depth adjustment, 4K enhancement, Frame interpolation, Horizontal and vertical keystone correction, Quick Corner, Wireless LAN capable
|
|
Video Color Modes
|
Automatic, Cinema, Dynamic, Natural, Bright Cinema
|
|
Power consumption
|
387 Watt, 297 Watt (economy), 0.5 Watt (standby), On mode power consumption as defined in JBMS-84 323 Watt
|
|
Supply Voltage
|
AC 100 V - 240 V, 50 Hz - 60 Hz
|
|
Product dimensions
|
410 x 310 x 157 mm (Width x Depth x Height)
|
|
Product weight
|
6.9 kg
|
|
Noise Level
|
Normal: 32 dB (A) - Economy: 24 dB (A)
|
|
Supported Temperature
|
Operation 5° C - 30° C, Storage -10° C - 60° C
|
|
Supported Humidity
|
Operation 20% - 80%, Storage 10% - 90%
|
|
Options
|
Air filter ELPAF38, MB22 ceiling mount, Wireless LAN unit
|
|
Loudspeaker
|
10 Watt, Stereo: Stereo
|
|
Room Type / Application
|
4K Gaming, 4K Streaming, Home Cinema, Sports, TV & Box sets
|
|
Positioning
|
Ceiling Mounted, Desktop
|
