| Amplifier |
|
| Total Amplifier Power (FTC) |
370W (FTC Power Output Rating) |
| Total Amplifier Power (Peak) |
860W (This rating was not tested under the FTC standard) |
| Total Amplifier Power (Peak, Raw Amplifier Power) |
1400W (This rating was not tested under the FTC standard) |
| Amplifier Topology |
Marantz Rise GaN FET |
| Loudspeaker Array |
|
| Bass |
1×8" Marantz Gravity |
| Wideband |
4×3" |
| High Frequency |
3×1" |
| Performance |
|
| Frequency Response |
28Hz to 20kHz (+/-3dB), 18Hz (-10dB) |
| Maximum SPL |
111dB (1M) |
| Peak SPL |
122dB (1M) |
| Audio Connectivity |
|
| Analog |
1 pr. RCA L/R |
| Digital |
1 ea. TOSLINK Optical |
| USB |
1 ea. USB-C (Mass Storage) |
| HDMI |
1 ea. eARC / ARC |
| Audio Format Support |
|
| Decoding |
Dolby Atmos, Dolby TrueHD, DSD, Dolby Digital+, Dolby Digital, LPCM |
| Max PCM Sample Rate / Bit Depth |
Stereo: 192kHz / 24 bit, Multi-Channel: 192kHz / 24 bit (7.1 Channel) |
| Max DSD Data Rate |
5.6 MHz (DSD ×2) |
| Stereo File Formats (HEOS network share or USB) |
WMA: up to and including 192 kbps, AAC & MP3: up to and including 320 kbps, WAV, ALAC, FLAC: up to and including 24-bit/192kHz, DSD: 2.8 MHz, 5.6 MHz |
| Streaming Technologies |
|
| Bluetooth |
BT 5.4 |
| AirPlay |
AirPlay 2 |
| Spotify |
Spotify Connect |
| Music Services and Sources |
|
| Music Services Supported (HEOS, subject to change and local availability) |
Pandora, Spotify, TuneIn, SiriusXM, Amazon Music, TIDAL, iHeartRadio, Deezer, Deezer HiFi, Mood:Mix, Sony Hi-Res, AWA, Play, SoundCloud |
| Music stored on mobile device |
Yes (iOS, Android, or Kindle Fire) |
| NAS (Network Attached Storage) |
Network share, UPnP |
| USB Storage Device Playback |
Yes (FAT32, NTFS formatted drives) |
| Networking & Control |
|
| Wired Connectivity |
Ethernet |
| Wireless Connectivity |
Dual band, 802.11 a/b/g/n/ac/ax |
| Control System Compatibility via TCP/IP |
Crestron, Control4, AMX |
| HEOS App |
iOS, Android, Kindle Fire |
| General |
|
| Product Color |
Moon Ray, Midnight Sky, Marantz Champagne |
| Included |
Certificate of Authenticity, QSG, Power Cable, HDMI Cable |
| User Interface |
Volume up/down, Play / Pause, Multi colored LED status indicator, Connect button (rear), Bluetooth button (rear) |
| Dimensions (H × W × D) Inches |
19.41 × 10.04 × 20.83 |
| Dimensions (H × W × D) mm |
493 × 255 × 529.2 |
| Weight (lbs) |
46.9 |
| Weight (kg) |
21.3 |
