Number of Poweramps
|
7
|
|
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)
|
70 W
|
| Power Output (6 ohm, 1 kHz, 1% 1ch Drive) |
90 W |
|
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
|
50 W
|
| Network Control On Consumption in W |
3.7 W |
| Power Consumption in W |
250 W |
| Power consumption No-Sound (ECO on / off) in W |
30 W / 40 W |
| Standby Consumption in W |
0.2 W |
| HDMI |
- DSD Audio capability: -
- HDCP2.3 support: Yes
- HDMI: 8K / 4K / CEC / eARC: Yes
- HDMI: ALLM / QMS / QFT / VRR: Yes
- HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG: Yes
- HDMI inputs back / front: 6 / 0
- HDMI max Resolution (8k / 4k): 8k/60 - 4k/120**
- HDMI outputs main / zone: 1 / -
- HDMI pass-though in standby mode: Yes
- HDMI to HDMI scaling: up to 8K 60/50
- Video conversion Analog -> HDMI: -
|
|
Inputs/Outputs |
- 7.1 multichannel input: -
- Analogue In / Out: 3 / -
- Bi-amp drive: assignable
- Component In / Out: 2 / 1
- Composite In / Out: 3 / 1
- DAB / DAB+ tuner: -
- Digital in: optical / coaxial: 1 / 1
- FM Tuner with RDS: Yes
- Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB - / - / - / - / Yes
- HDMI In / Out: 6 / 1
- Multichannel Pre Out: Yes (2.2)
- Multi-Room Out: analog / digital: 1 / -
- Multi-Room Speaker Terminal: assignable
- Multi-Room Video Out: Video / HDMI: - / -
- Number of speaker terminals 7
- Phono (MM) In: Yes
- Speaker A / B: assignable
- Speaker Terminal: Gold plated screw / regular screw: - / Yes
- Subwoofer Out: 2
- USB Audio / Made for iPod / Works with iPhone: Yes / AirPlay / AirPlay
|
Multichannel Surround
|
- Auro 3D: -
- Dolby Height Virtualization: Yes
- Dolby ProLogic Il / Dolby Surround: - / Yes
- Dolby TrueHD / Dolby Atmos: Yes / Yes
- DTS HD Master / DTS:X: Yes / Yes
- DTS Neo:X / DTS Neural:X: No / Yes
- DTS Virtual:X: Yes
- DTS:X Pro: -
- Front Wide Speakers: Dolby / DTS: -
- IMAX Enhanced: -
- max. number of processing (preamp) channels 7.1
- MPEG-H: -
- Multichannel Stereo: Yes
|
| System Remote Control |
RC042SR |
|
Maximum Dimensions (W x D x H)
|
Antenna:Horizontal:
440 x 378 x 105 mm
Antenna: Vertical:
440 x 378 x 173 mm
W/o Antenna:
440 x 378 x 173 mm
|
| Weight |
18.3 lbs / 8.3 kg
|
