The C 388 Hybrid Digital DAC Amplifier is at the top of its class in the world of affordable amplification. An incredibly powerful amp, the C 388 employs NAD technologies like Asymmetrical PowerDrive™ to ensure that even the most demanding speakers can be driven to life-like listening levels without dynamic compression. Thanks to its advanced preamplifier circuit, the C 388 gives low noise at all volume settings, ensuring that you’ll be able to listen to your music without any distractions. Another technology that’s available to the C 388 is the BluOS™ module, a music management system that can stream your music library wirelessly across your home Wi-Fi network. Connect to the C 388 instantly with Bluetooth® to give you access to various streaming services. With the ability to accommodate a variety of sources both past and present, the C 388 is a remarkably flexible product that will become a core addition to your home audio system.
KEY FEATURES
-
150W x 2 Continuous power into 8 or 4 Ohms
- MM Phono input
- USB port for service purposes
- Speaker A, Speaker B
- Headphone amplifier
- IR remote
- 12V Trigger in/out
- RS-232 Serial port for control
- Bluetooth A2DP with aptX supported
- Analogue line inputs
- SPDIF coax and optical inputs
- Preamp/Subwoofer out
- MDC Slots for future upgrades
- Smartphone Control App
- IR in/out
- Control4, Crestron, RTI, URC, AMX, Savant, Elan certified
Technical Specification
-
Line Input, Pre Out
THD (20Hz-20kHz) - <0.005% at 2V out
Signal/Noise Ratio - >106dB (IHF; A-weighted, ref. 500mV out, unity gain)
Channel Separation - >80dB (1kHz); >70dB (10kHz)
Input Impedance (R and C) - 22 kilohm + 100pF
Maximum Input Signal - >4.5Vrms (ref. 0.1% THD)
Output Impedance - Source Z + 240 Ohm
Input Sensitivity - 93mV (ref. 500mV out, Volume maximum)
Frequency Response - ±0.03dB (20Hz-20kHz)
Maximum voltage output – IHF load - >4.5V (ref. 0.1% THD)
Tone Controls - Treble: ±7.0dB at 20kHz
Bass: ±7.0dB at 60Hz
Balance: -10dB
-
Phono Input, Pre Out
THD (20Hz-20kHz) - <0.01% at 2V out
Signal to Noise Ratio - >84dB (200 Ohm source; A-weighted, ref. 500mV out)
>76dB (MM cartridge source, IHF; A-weighted, ref. 500mV out)
Input Sensitivity - 1.44mV (ref. 500mV out, Volume maximum)
Frequency Response - ±0.3dB (20Hz-20kHz)
Maximum Input Signal at 1kHz - >80mVrms (ref. 0.1% THD)
-
Line Input, Headphone Out
THD (20Hz-20kHz) - <0.005% at 1V out
Signal/Noise Ratio - >110dB (32 Ohm loads; A-weighted, ref. 2V out, unity gain)
Frequency Response - ±0.3dB (20Hz-20kHz)
Channel Separation - >60dB at 1kHz
Output Impedance - 6 Ohms
-
General Specifications
Continuous output Power into 4 Ohms and 8 Ohms (Stereo) - >150W (at rated THD, 20-20kHz, both channels driven)
IHF Dynamic Power - 8 Ohm 250W
4 Ohm 350W
2 Ohm 400W
THD (20Hz-20kHz) - <0.02% (250mW to 150W, 8 Ohm and 4 Ohm)
Signal/Noise Ratio - >95dB (A-weighted, 500mV input ref. 1W out in 8 Ohm)
Clipping Power - >160W (at 1kHz 0.1% THD)
Peak Output Current - >20A (in 1 Ohm, 1ms)
Damping Factor >150 (ref. 8 Ohm, 20Hz and 6.5kHz)
Frequency Response - ±0.03 (20Hz-20kHz)
Channel Separation - >75dB (1kHz)
>70dB (10kHz)
Input Sensitivity (for 80W in 8 Ohm) - Line In: 490mV; Phono In: 7.5mV; Digital In: 24% FS
Sample Rate - up to 24 bit/192kHz
Frequency Band - 2.402G – 2.480G
Maximum Transmit Power (dBm) - 7dBm ±2dBm
-
Power Consumption
at Auto Standby ON and Network Standby OFF - 0.5 Watts*
at Auto Standby ON and Network Standby ON - 1.2 Watts**
OFF mode (Power switched OFF) - 0.1 Watts
-
Weight & Dimensions
Gross Dimensions (W x H x D)* - 435 x 120 x 390mm (17 1/8 x 4 3/4 x 15 3/8)”
Net Weight - 11.2kg (24.7lb)
Shipping Weight - 13.6kg (30lb)
Condition
- Product comes with 1 year warranty from the date of purchase.
- Product is just used for demo purpose.
- Product is in excellent condition
