High-performance mineral-filled polypropylene cones with inverted dust caps are lightweight and rigid. Downroll surrounds give them a clean, low-profile look.
Beautiful Monitor SE speaker cabinets, with their unmistakably European fit and finish, complement today’s most stylish décor. Each model is available in high-gloss white or matte black finishes.
Partnered with the NRC
Paradigm is partnered with Canada’s world-renowned NRC in ongoing research to reveal the true nature of sound and human hearing. Findings influence design and performance specs, resulting in a uniquely realistic listening experience, backed by sound science
Technical Specifications :
IFICATIONS
| DESIGN |
5-driver, 3-way bass reflex, floorstanding |
| CROSSOVER |
2nd-order electro-acoustic at 3.0 kHz (tweeter/mid) and 800Hz (mid/woofers) |
| HIGH FREQUENCY DRIVER |
1” (25mm) X-PALTM dome, ferro-fluid damped/ cooled, Perforated Phase- Aligning (PPATM) Lens |
| FREQUENCY RESPONSE ON-AXIS
|
±3dB from 45 Hz - 21 kHz |
| FREQUENCY RESPONSE 30° OFF-AXIS
|
±3dB from 45 Hz - 17 kHz |
| MIDRANGE FREQUENCY DRIVER |
6-1/2” (165mm) mineral- filled polypropylene cone/inverted dust cap/downroll surround |
| LOW FREQUENCY DRIVER |
Three 8” (203mm) mineral-filled polypropylene cones/ inverted dust cap / downroll surrounds |
| SENSITIVITY ROOM / ANECHOIC |
95 dB / 92 dB |
| LOW FREQUENCY EXTENSION |
35 Hz (DIN) |
| SUITABLE AMPLIFIER POWER RANGE |
15 - 150 watts |
| MAXIMUM INPUT POWER |
150 watts |
| IMPEDANCE |
Compatible with 8 ohms |
| FINISHES |
Matte Black, Gloss White |
| DIMENSIONS HXWXD
|
45.88” x 11.75” x 17.69” (116.5 x 29.8 x 44.93cm) |
| WEIGHT |
69 lbs. (32.2 kg) |
