Enjoy a multitude of audio entertainment from various sources, including Hi-Res Audio files, internet radio, network streaming services, and even vinyl records with the SX-N30AE network stereo receiver, equipped with a discrete high-output amplifier. Bluetooth® Wireless Technology, dual-band Wi-Fi, FlareConnect™, Chromecast built-in, and DTS Play-Fi® let you wirelessly stream songs, while the Pioneer Remote App offers smooth control on your smartphone. The SX-N30AE also works with the Google Assistant.

Amplification & Design

• Application Type: Direct Energy
• Analogue Discrete 2ch Amplifier
• Large EI Transformer
• Two Large Custom 8,200 μF Capacitors
• 135 W/ch (6 ohms, 1 kHz, THD 1.0 %, 1ch Driven)
• Screw Type Speaker Terminals Compatible with Thick Cables

Audio & Home Network Features

• Direct Mode
• Music File Playback via Network/USB: MP3, WMA, WAV, AIFF,
• AAC, FLAC, and Apple Lossless
• 192 kHz/24-bit Audio Playback (WAV*1, FLAC*1)
• DSD Direct Playback (2ch, 5.6 MHz)
• Spotify®, TIDAL, and Deezer Digital Music-Streaming Services Ready*2
• Internet Radio with TuneIn
• FlareConnect™ for Multi-room Audio
• Chromecast built-in
• Works with the Google Assistant*3
• DTS Play-Fi Ready*3

Convenience Features

• Dual-Band Wi-Fi (5 GHz/2.4 GHz)
• Bluetooth® Wireless Technology (Ver. 4.1 + LE, Profile: A2DP/
• AVRCP/HOGP-Host/HOGP-HID Device/HID Service, Codec: SBC/
• AAC)
• Works with Pioneer Remote App (iOS/Android)*4
• AM/FM (RDS) Tuner with 40 Station Presets
• Preset Station Naming (Up to 10 Characters)
• Auto Standby
• SR Remote Control

Terminals

• Front USB 1 in
• Phones 1 out
• Ethernet 1 in
• Analogue Audio in (Phono MM, SACD/
• CD, TV, GAME, AUX, SAT/CBL, BD/DVD)
• Line 2 out
• Digital Coaxial 1 in
• Digital Optical 1 in
• Subwoofer Preout

SPECIFICATIONS

• Power Requirements: AC 220-230 V,
• 50/60 Hz
• Power Consumption (in Use/in Standby):
• 220 W/0.1 W
• Dimensions (W x H x D): 435 x 149 x 327 mm
• Weight (Without Package): 8.3 kg
