Audio Features
IMAX Enhanced*1
Dolby Atmos®, Dolby Surround Upmixer
DTS:X®, DTS Neural:X® Upmixer
Reflex Optimizer
Dolby Atmos Height Virtualizer*1
Dolby® TrueHD, Dolby Digital Plus
DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS Express
DSD Disc (SACD) Playback via HDMI (2.8 MHz/2 ch, 5.1 ch)
Digital Quad-Core 32-bit DSP (Cirrus Logic) + Aureus™ floating-point DSP (TI)
384 kHz/32-bit D/A Conversion with AK4458 (AKM) & PCM5101A (TI)
Audio Return Channel (ARC) on HDMI
Advanced MCACC Auto Room Tuning
- Auto Phase Control Plus
- Subwoofer EQ
- Multi-point Standing Wave Control
Advanced Sound Retriever (2ch)
Advanced Surround Modes
Classical, Unplugged, Entertainment Show, Drama, Advanced Game, Action, Rock/Pop, Sports, Extended Stereo, Extended Mono, Front Stage Surround Advance
Video Features
Ultra HD Pass-through with HDCP 2.3 (4K/60p/4:4:4/24-bit, 4K/24p/4:4:4/36-bit, 4K/60p/4:2:0/36-bit)*2
HDR10, HLG and BT.2020 Compliant Wide Colour Gamut Signal Pass-through
Dolby Vision™ Compatible
Ultra HD Upscaling (1080p to 4K)
3D Ready (Blu-ray Disc™, Broadcast, and Games)
Deep Colour (36-bit), “x.v.Colour”
Home Network Features
FlareConnect™ for Multi-room Audio
Chromecast built-in*3 and Works with the Google Assistant
DTS Play-Fi with Pioneer Music Control App
Apple AirPlay 2
Works with SONOS
Amazon Music*4, Spotify Freemium*5, Spotify Premium*5, TIDAL*5, and Deezer*5
Music-Streaming Services Ready
Internet Radio with TuneIn
Hi-Res Audio File Playback via USB/Network
- Up to 192 kHz/24-bit ALAC*6, AIFF , FLAC, WAV (RIFF ) and 11.2 MHz DSD*7
Convenience Features
Personal Preset
Dialog Enhancement
Dual Band (5 GHz/2.4 GHz) 802.11ac Compliant Wi-Fi® Built-in
Bluetooth® Wireless Technology (Version: 4.2 + LE, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/AAC) Built-in
Pioneer Remote App*8 Ready for Multi-room Entertainment Control and Network Streaming
User-Friendly GUI with System Setup Menu
On-Screen Information for Audio/Video Status
Auto Power Off in HDMI Standby Through
AM/FM Tuner 40 Presets
Sleep Timer
User-Friendly Simple Remote Control
Front Terminals
HDMI 1 In
USB 1 In for USB Drive
MCACC Setup MIC In (Gold-Plated)
Audio 1 In (Mini Stereo Jack, Gold-Plated)
Phones 1 Out
Rear Terminals
HDMI 6 In (4 Assignable)
HDMI 2 Out (1 for MAIN, 1 for SUB)
Ethernet 1 In
USB 1 In for USB Drive
Audio 4 In (Assignable)
Phono (MM) 1 In
Digital Coaxial 1 In (Assignable)
Digital Optical 1 In (Assignable)
Subwoofer 2 Pre Out
ZONE B Line Out for Wireless Headphones
ZONE 2 Pre/Line Out
Speaker 9ch Out (FRONT , CENTER, SURROUND, HEIGHT 1/Bi-AMP /ZONE 2, SURROUND BACK/HEIGHT 2/ZONE 3)
IR 1 In/1 Out
12 V Trigger 2 Out
RS-232C
FM/AM Antenna
Specifications
Power Requirements: AC 220-240 V, 50/60 Hz
Power Consumption/Standby: 760 W/ 0.15 W
Dimensions (W x H x D): 435 x 173 x 370.5 mm
Weight: 10.8 kg
