Tannoy - Revolution XT Mini [Light Oak] [New Sealed Box]

₹ 24,640.00 was ₹ 55,000.00

This product is currently sold out.

Please fill in the form below if you'd like to be notified when it becomes available.

Specification

Performance
Recommended Amplifier Power<br />(Watts RMS)

25 - 100

Continuous Power Handling<br />(Watts Peak RMS)

50

Peak Power Handling (Watts)

200

Sensitivity (2.83 Volts @ 1m)

88 dB

Nominal Impedance (Ohms)

8

Frequency Response (-6dB)

68 Hz - 52 kHz

Drive Units
Dual Concentric™ High Frequency

20 mm (0.79”) Linear PEI dome with Torus Ogive WaveGuide and Omnimagnet technology

Dual Concentric™ Low Frequency

100 mm (4”) multi-fibre paper
35 mm (1.38”) voice coil

Bass Driver

-

Crossover
Crossover Frequency

2.8 kHz

Crossover Type

Passive low loss 2nd order low pass, 1st order high pass

Construction
Enclosure Type

Rear ported reflex

Volume

3.4 l (0.12 cu. ft.)

Dimensions H x W x D<br />(incl. plinth)

272.2 x 152 x 199.3 mm
(10.7 x 6.0 x 7.8”)

Weight

3.7 kg (8.1 lbs)
