Compact, Powerful Sound in a Smaller Package
Our most compact headed model brings all the technical advantages of a dedicated midrange enclosure – the Turbine™ Head, with its decoupled midrange cone – to a smaller footprint that’s easily accommodated in any home. With advanced technology and sleek design, this model offers exceptional sound quality without taking up much space.
Key Features
- Diamond tweeter for superior high-frequency performance
- Solid body Tweeter-on-Top for optimal sound dispersion
- Continuum™ cone FST for precise and natural midrange sound
- Matrix™ and Anti-Resonance plug for enhanced clarity
- Biomimetic Suspension for improved damping and performance
- Turbine™ Head for a decoupled midrange cone, improving sound definition
- Aerofoil™ cone bass units for deep, powerful bass
- Flowport for reduced distortion and increased airflow
- Elegant finishes available in Gloss Black, White, Satin Rosenut, and Satin Walnut
Technical Specifications
| Specification |
Details |
| Size & Weight |
Net weight: 62.15kg (137 lb) |
| Dimensions |
Height: 1165mm (45.9 in), Width: 357mm (14.1 in), Depth: 511mm (20.1 in) |
| Description |
3-way vented-box system |
| Drive Units |
1x ø25mm (1in) Diamond dome high-frequency, 1x ø130mm (5in) Continuum cone FST midrange, 2x ø180mm (7in) Aerofoil cone bass units |
| Frequency Range |
16Hz to 35kHz |
| Frequency Response |
19Hz to 28kHz (+/-3dB from reference axis) |
| Sensitivity |
90dB (on axis at 2.83Vrms at 1m) |
| Harmonic Distortion |
2nd and 3rd harmonics (90dB, 1m on axis) < 1% (80Hz – 20kHz), < 0.3% (100Hz – 20kHz) |
| Nominal Impedance |
8Ω (minimum 3.0Ω) |
| Recommended Amplifier Power |
50W – 500W into 8Ω on unclipped programme |
| Max Recommended Cable Impedance |
0.1Ω |
| Finishes |
Gloss Black, White, Satin Rosenut, Satin Walnut |
| Grille Finishes |
Black, Grey |
